1.02 inch mini partial refresh E Ink display, GDEW0102T4

Categroy:

Small E-Paper

This is a mini partial refresh E Ink display, 1.02 inch, with 128x80 resolution, UC8175, SPI interface, and the epaper screen supports partial refresh.

Buy It Now
  • Description
  • Specification
  • Video
    • Commodity name: 1.02 inch mini partial refresh E Ink display, GDEW0102T4
    • Commodity ID: 946447827884400640

    This is a mini partial refresh E Ink display, 1.02 inch, with 128x80 resolution, UC8175, SPI interface, and the epaper screen supports partial refresh.

    INTRODUCTION

    This is a 1.02 inch mini partial refresh E Ink display with 128x80 resolution, SPI interface, and the display is capable to display images with black and white content. Your image holds indefinitely without power – put up your image, then shut down the power. This E Ink display GDEW0102T4 is perfect for low power devices powered by solar or batteries.

    We could provide Front light, Touch screen and other accessories for you.

    Use our free e-paper software to prepare your bitmap image for this display.

    You can refer to the following link for the procedures and instructions of automatic e-paper display bitmap conversion:

    https://github.com/abao66669999/Good-Display-Software




    FEATURE

    ●  Black and white monochrome is easy to read

    ●  Versatile. Use in portrait or landscape format

    ●  It supports partial refresh, the refresh rate is 0.3s/frame

    ●  Bistable. (Will continue to display with no power source)

    ●  I2C Signal Master Interface to read external temperature sensor





    DEVELOPMENT PLATFORM AVAILABEL

    We have this e-paper Adapter Board that makes connecting our ePaper simple and fast.



    STM32 Arduino UNO ESP8266

    Raspberry Pi ESP32











    Keywords:
    • 1.02 inch mini e-paper display module partial refresh
  • PARAMETERS



    PART NUMBER

    GDEW0102T4

    TYPE

    Dot Matrix

    SIZE

    1.02 inch

    IC

    UC8175

    RESOLUTION

    128x80

    OUTLINE SIZE(mm)

    32.57x18.6x0.98

    ACTIVE SIZE(mm)

    21.76x14

    PIXEL PITCH(mm)

    0.175x0.17

    OPERATING TEMP.

    0℃~50℃

    STORAGE TEMP.

    -25℃~70℃

    CONNECTOR

    30 Pin

    MAX GRAYSCALE

    2

    COLOR

    Black,White

    INTERFACE

    SPI

    FULL REFRESH(s)

    3

    PARTIAL REFRESH TIME(s)

    0.3

    POWER CONSUMPTION OF THE REFRESH(mW)

    26.4

    STANDBY POWER CONSUMPTION (mW)

    0.0165







    DRAWING










  •
