1.29 inch OLED display module with adapter board, wide temperature

Categroy:

OLED

Keywords:

paper


messages
Buy It Now
  • Description
  • Specification
  • Video
    • Commodity name: 1.29 inch OLED display module with adapter board, wide temperature





    INTRODUCTION

    GDMN0129PGWP30 consists of a 1.29 inch OLED display and its adapter board. It suits for STM32 Platform, Arduino Platform and Raspberry Pi Platform. The adapter board's main function is to provide a communication interface and power supply for this 1.29 inch OLED display. At the same time, it is convenient for users to quickly master the use of the OLED display.

    Self-luminous, no backlight required. This reduces the power required to run the OLED and it is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature. It can be used in any embedded systems,industrial device,security,medical and hand-held device.





    FEATURE

    ● Self-luminous, no backlight is required.
    ● High contrast,extremely wide viewing angle
    ● It suits for STM32 Platform, Arduino Platform and Raspberry Pi Platform.
    ● Wide operating temperature: -40℃~85℃





    Keywords:
    • 1.29 inch OLED display module with adapter board wide temperature
  •

    PARAMETERS

    PART NUMBER GDMN0129PGWP30
    DIAGONAL SIZE 1.29"
    DISPLAY MODE Passive Matrix
    DISPLAY COLOR White

    DRIVE Duty

    1/64 Duty

    INTERFACE 8-bit 68XX/80XX Parallel, 4-wire SPI, I2C
    Driver IC SSD1315
    OUTLINE DIMENSION(mm)

    Display: 32.42x21.36x4

    Connector board: 39.8x27.8

    ACTIVE AREA(mm) 29.42x14.7

    PIXEL PITCH(mm)

    0.23x0.23

    PIXEL SIZE(mm)

    0.21x0.21

    BRIGHTNESS(Typ) 110 cd/m2
    VIEW ANGLE Free
    OPERATING TEMP. -40℃~85℃
    POWER SUPPLY 3.3V

    MAIN FUNCTION

    1. Provide communication interface and  power supply for OLED

    2. It is convenient for users to quickly master the use of OLED display.

    ACCESSIBILITY

    1. OLED display power consumption measurement     2. OLED display working state detection







    DRAWING
